OneUp Components

Wave Pedals

UPC: 0628219407412

Colour — Dark Green Dark Green Black Red Purple

Price

~~$0.00~~

Save

/

Pairs well with

New

This product is from a Canadian brand.

Discover more Canadian-branded products.

Wave Pedals

OneUp Components

Price match guarantee

Free shipping over $74.00*

Locally owned

Secure payments

Best Use:: Mountain
Weight:: 355g (Pair)
Cleat Type:: n/a
Cleats Included:: n/a

Get ultimate grip and bike control with our innovative Wave profile.

Most flat pedal profiles are either convex or concave. Wave is a patented hybrid convex/concave shape that promotes an aggressive heels-dropped riding position and gives you a more natural pedal stroke when seated. With Wave, your foot is being held by the shape of the pedal - not just the pins.

What's in the Box:

2x Wave Pedals (1x Left, 1x Right)
9x Installed M4 hollow threaded pins per side (36x pins total)
10x Spare/Uninstalled M4 hollow threaded pins
1x Pedal Bearing Nut Tool

Convex + Concave = Wave: The front half of the pedal has a concave profile that hugs the ball of your foot for unmatched grip. The back half of the pedal is sloped to promote an aggressive heels-down foot position for more power and control.
Angled Pins: Because the Wave design naturally encourages your heels to drop, the pins are installed at an angle to be vertical when riding. This leverages the Wave profile and increases grip - without the need for longer pins.
DH-Rated Axle: The Wave pedal uses a proven axle, bushing and bearing configuration for improved reliability — strong enough for all types of riding.

Weight: 355g (Pair)
Thickness: Axle 14.2mm / Edges 11.5mm
Size: 107mm x 110mm (W x L)
Bearing configuration: Inboard igus™ Bushing and 3x outboard cartridge bearings
Body: Forged and CNC’d 6061 Aluminum Body
Axle: Chromoly Steel with Black ED coating
Pins: M4 Hollow Pin 10 x pins per side (self-cleaning hex through hole)
