Orbea

Laufey H30

UPC: 8434446144967
Buy a Bike - Save 15% off Regular Price Cycling Accessories, Apparel, and Gear!
Colour — Digital Lavender - Acid Gum (Gloss)
Size
Size chart
 Size  Rider Height
SM

150 - 165 cm

59.1"-65.0"
MD

160 - 175 cm

63.0"-68.9"
LG

170 - 185 cm

66.9"-72.8"
XL

180 - 198 cm

70.9"-78.0"


Price
Save
/

Pairs well with
Frame:
Orbea Laufey Hydro Triple Butted
Fork:
RockShox Recon RL
Rear Suspension:
n/a
Tires:
Maxxis Dissector 2.40"
Wheels:
Alloy, Tubeless, 29", 29c, 32H
Rear Derailleur:
Shimano Deore M6200 SGS Shadow Plus
Brakes:
Shimano MT201 Hydraulic Disc
Seatpost:
Shimano SL-MT500
Stem / Handlebar:
Alloy 3D forged
Weight (lbs/kg):
n/a
Sizes:
LG
  • Price match guarantee
  • Locally owned
  • Secure payments

Laufey is our hardtail trail bike, eager to take on any party lap or forest loop you can think of.

Riding a hardtail is a choice, not a compromise. When you throw a leg over Laufey you've already decided to squeeze every last drop of fun from each ride.

  • Big Forks: The long travel 140mm fork matches Laufey's fun loving nature, letting you push hard even when things get rough.
  • Steep 'N' Deep: Thanks to the uninterrupted, short and straight seat tube Laufey has space for fully inserting long travel dropper posts on all sizes. Drop your saddle right out of the way on the descents, giving more space to more your body and more control. Long travel droppers are the only way!
  • Low Slung: The sloping top tube works with Steep´n´Deep, giving loads of space to maximize Laufey's playfulness.
  • Burly Tire Clearance: Laufey's carefully shaped chainstays offer plenty of clearance for 2.6" tires.

Frameset

  • Frame: Orbea Laufey Hydro Triple Butted 29" Boost 12x148 ISCG 05
  • Fork: RockShox Recon RL 15X110 Boost Solo Air 140mm
  • Steerer tube: Acros Alloy 1-1/8 - 1-1/2" Integrated

Drivetrain

  • Crankset: Forged alloy, 32t
  • Shifters: Shimano Deore M6200
  • Cassette: Sun Race 11-51t 12-Speed
  • Rear derailleur: Shimano Deore M6200 SGS Shadow Plus
  • Chain: KMC X12

Cockpit

  • Handlebar: OC Mountain Control MC30, Rise20, Width 800
  • Stem: Alloy 3D forged, 35mm interface, -7º

Brakes

  • Brakes: Shimano MT201 Hydraulic Disc

Wheels

  • Wheels: Alloy, Tubeless, 29", 29c, 32H
  • Tires: Maxxis Dissector 2.40" 60TPI Rigid EXO/TR

Components

  • Seatpost: OC Mountain Control MC22, 31.6mm, Dropper
  • Seatpost Lever: Shimano SL-MT500
  • Saddle: Selle Royal 2058 DRN
  • Grips: OC Lock On

 *Subject to change without notice

Big Forks

The long travel 140mm fork matches Laufey's fun loving nature, letting you push hard even when things get rough.

Burly Tire Clearance

Laufey's carefully shaped chainstays offer plenty of clearance for 2.6" tires.

Internal Cables

The internal cable routing guides cables through the downtube and chainstays to ensure no rubbing or rattling.
