Speed Concept SLR 7 AXS

• Smart integrated fuel and hydration storage makes it simple and stress-free to stay strong without leaving your aero position
• Top Tube IsoSpeed takes the edge off rough roads and is damped with an elastomer so it rebounds in a smooth, controlled, stable motion
• Easy build, easy travel: fast assembly makes it easier to travel to races
• The wireless electronic Ultegra Di2 delivers faster, smoother, and more responsive shifts than ever
• Make it yours: it's fully customizable through Project One. Choose your model. Choose your paint. Choose your parts.

FramesetFrame

• 800 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, T47 BB, integrated Bento box, integrated downtube storage

Fork

• SC full foil carbon, integrated brake & stem

Frame fit

• Triathlon

Weight

Weight

• M - 19.89 lbs / 9.02 kg

Weight limit

• This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).

Drivetrain

Shifter

• SRAM AXS Wireless Blips, basebar and extension-mounted

Front derailleur

• SRAM Force AXS, braze-on

Rear derailleur

• SRAM Force AXS, 36T max cog

Crank

• Size: S: SRAM Force AXS with power meter, 48/35, DUB, 165mm length
• Size: M, L: SRAM Force AXS with power meter, 48/35, DUB, 170mm length
• Size: XL: SRAM Force AXS with power meter, 48/35, DUB, 172.5mm length

Bottom bracket

• SRAM DUB, T47 threaded, internal bearing

Cassette

• SRAM Force XG-1270, 10-33, 12 speed

Chain

• SRAM Force E1, 12/13 speed

Max chainring size

• 1x: 58T, 2x: 55/44

Wheels

Wheel front

• Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle

Wheel rear

• Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, SRAM XD-R driver, 142x12mm thru axle

Skewer front

• Bontrager Switch thru axle, removable lever

Skewer rear

• Bontrager Switch thru axle, removable lever

Tire

• Bontrager R4 320, 700x25mm

Max tire size

• 28mm rear, 25mm front

Components

Saddle

• Bontrager Hilo Pro Carbon

Seatpost

• Size: S
  Speed Concept SLR, 11.5mm or -20mm offset, short length.
• Size: M, L, XL
  Speed Concept SLR, 11.5mm or -20mm offset, tall length

Handlebar part:

• Size: S, M
  Speed Concept 30mm Base Tower
• Size: S, M, L, XL
  Speed Concept 45mm Base Tower
• Size: L, XL
  Speed Concept 60mm Base Tower
• Size: S
  Speed Concept Cockpit Tower Topper Near
• Size: M, L, XL
  Speed Concept Cockpit Tower Topper Mid

Handlebar/stem(integrated)

• Speed Concept mid-rise bar/stem

Handlebar tape

• Trek EcoTack

Brake

• SRAM S-900 Aero

Brake rotor

• SRAM Paceline X, rounded, centerlock, 160mm

Rotor size

• Max brake rotor sizes: 160mm front & rear

Accessories

Cage

• Speed Concept Downtube Bottle Cage

Bottle

• Speed Concept Downtube Bottle

Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
