Trek

Checkpoint SL 7 AXS Gen 2

UPC: 768682497043
Color — Radioactive Red
Size
Price
Save $0
/

Pairs well with
  • Price match guarantee
  • Free shipping over $49*
  • Locally owned
  • Secure payments
Size chart
 Size  Rider Height  Inseam
49

156 - 163 cm

5'1" - 5'4"



74 - 77 cm

29" - 30"
52

163 - 168 cm

5'4" - 5'6"



76 - 79 cm

30" - 31"
54

168 - 174 cm

5'6" - 5'9"



78 - 82 cm

31" - 32"
 56

174 - 180 cm

5'9" - 5'11"



81 - 85 cm

32" - 33"
58

180 - 185 cm

5'11" - 6'1"



84 - 87 cm

33" - 34"
 61

185 - 191 cm

6'1" - 6'3"



86 - 90 cm

34" - 35"

Frame:
500 Series OCLV Carbon
Fork:
Trek Checkpoint, full carbon
Tires:
Bontrager GR1 Team Issue
Wheels:
Front: Bontrager Aeolus Pro 3V
Rear Derailleur:
SRAM Force XPLR AXS D2
Brakes:
SRAM Force AXS hydraulic disc, flat mount
Saddle:
Bontrager Verse Comp
Stem / Handlebar:
Bontrager Pro / Bontrager Elite Gravel
Tire Clearance:
45mm Max
Sizes:
49, 52, 54, 56, 58, 61
Weight (lbs/kg):
56 - 20.2 / 9.16 (with TLR sealant, no tubes)

Checkpoint SL 7 AXS pairs a light OCLV Carbon gravel frame with IsoSpeed and high-tech parts picked for performance and incredible ride quality on the toughest and roughest gravel adventures.

A nimble, yet stable progressive geometry, a smart and smooth 1x12 SRAM Force XPLR AXS D2 wireless electronic drivetrain, carbon wheels, and internal storage give you the comfort and capability you need to tackle your next serious gravel, dirt, or all-road adventure.

  • The SRAM Force XPLR AXS D2 electronic drivetrain is smart, smooth, and completely wireless

  • The damped, controlled rebound of the IsoSpeed decoupler soaks up fatiguing bumps without bouncing you around

  • Massive tire clearance means you can use tires up to 45c for extra traction and stability in any condition

  • A sleek internal storage compartment gives you a versatile spot to stow tools and gear

  • Fork mounts, frame mounts, and rack and fender mounts allow you to carry all the gear you need for day trips and bikepacking adventures

Frame

  • 500 Series OCLV Carbon, IsoSpeed, internal cable routing, downtube storage door,
    3S chain keeper, T47 BB, rack and fender mounts, integrated frame bag mounts,
    flat mount disc, dropper post compatible, 142x12mm thru axle

Fork

  • Trek Checkpoint, full carbon, tapered carbon steerer, rack mounts, fender mounts,
    flat mount disc, 12x100mm thru axle

Rims

  • Bontrager Aeolus Pro 3V, OCLV Carbon, Tubeless Ready, 25mm rim width

Stem

  • Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 80mm length

Chain

  • SRAM Force, 12 speed

 Tires

  • Bontrager GR1 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 120 tpi,
    700x40mm

Brakes

  • SRAM Force AXS hydraulic disc, flat mount

Rotors

  • SRAM CenterLine X, centerlock, round edge, 160mm

Saddle

  • Bontrager Verse Comp, steel rails, 145mm width

Wheels

  • Front: Bontrager Aeolus Pro 3V, OCLV Carbon, Tubeless Ready, 25mm rim width,
    100x12mm thru axle
  • Rear: Bontrager Aeolus Pro 3V, OCLV Carbon, Tubeless Ready, 25mm rim width,
    142x12mm thru axle

Crankset

  • SRAM Force 1 D2, 40T, DUB, 172.5mm length

Seatpost

  • Bontrager carbon, 27.2mm, 8mm offset, 330mm length

Shifters

  • SRAM Force AXS D2, 12 speed // SRAM Force AXS D2, 12 speed

Handlebars

  • Bontrager Elite Gravel, 42cm width

Tape/Grips

  • Bontrager Supertack Perf tape

Bottom Bracket

  • SRAM DUB, T47 threaded, internal bearing

Rear Derailleur

  • SRAM Force XPLR AXS D2, 44T max cog

Accessories & Extras

  • Bontrager BITS Internal Frame Storage Bag

Cassette/Freewheel

  • SRAM XG-1271, 10-44, 12 speed

* Subject to change without notice.
